Clamp Parts Breakout

main components

[1] HBOLT 1.2500-7x12x12-N [ANT-124212] [qty 3x] & HEX NUT 1.25-7 [ANT-124211A] [qty 3x] *This is special bolt usually sold as an assembly.
[2] 200 CLAMP BODY [ANT-250101] [qty 1x]
[3] Nylatron Sleave [ANT-250202E-1] [qty 1x]
[4] Seal Plate "Gland" [ANT-250003] [qty 1x]
[5] Piston Rod [ANT-250004] [qty 1x] Piston o-ring + Expander ring (R-5100-128 #442-1) [ANT-222010] *Seals can be purchased as a kit
[6] Seal Plate bolts (HX-SHCS 0.625-18x1x1-N) [ANT-124212 [qty 12x]

[7] 90 degree 3/8" SAE to 3/8" JIC (FITT2L-6M06R) [ANT-222010] [qty 2x] *These also come in 45 degree angles
[8] 3/8" SAE plug [FITT2P-06R] [ANT-222017] [qty 1x]
[9] SAE Plug [qty 1x]
[10] Collar Lock Washer 1.25 [ANT-124205] [qty 8x]
[11] Clamp bucket bolts (HX-SHC 1.25-12x4.5x3.25N) [ANT-124204] [qty 8x]
[12] SAE Plug [qty 1x]
[13] Clamp Bucket [ANT-250002] [qty 1x]
[14] Jaw [ANT-250203T] [qty 1x] *There are several thickness of Jaws (see Jaw section)
